16 In 16 Out DSP Digital Processor AGC AFS 18dBu Sound Audio Processor

Brand Name : FHB Audio

Model Number : MX-1616-C

Certification : CE,ROHS

Place of Origin : China

MOQ : 2 Set

Price : USD

Payment Terms : T/T, Western Union

Supply Ability : 10000 Set per Month

Delivery Time : 1-10Set: 5-7day ;10-100Set:10-5Days

Packaging Details : Standard packaging;GW:3KG/Set;5Set in one Carton(60*60*36cm);

Products Name : Digital Signal Processor

Keyword : DSP Sound Processor,DSP Effect Proessor,DSP Audio Processor,DSP Audio Mixer

Model No. : MX-1616-C

Analog Channels : 16 input,16 output

Function : Automatic mixing,,AFS,AGC

DSP Chips : Dual Core Ti 450MHz FLOPS

Client Software : PC Software,Web control

Material : Aluminum

Channel isolation : 104dB @1k Hz

Common mode rejection : 70dB @80 Hz

Maximum input level : 18dBu

Certificate : CE,ROHS

Weight : 3Kg

Working Power Supply : AC110V-220V,50Hz/60Hz

Contact Now

professional sound system 16in 16out AFS digital audio marix processor

Main Features:

  • Suitable for meeting room, campus, art performance, concert and other scene areas
  • Provide PC software and web control
  • System built-in lock screen function, can effectively avoid the wrong operation.
  • DSP audio processing, built-in automatic mixer, feedback elimination(AFS),AGC function
  • Input per channel: Front stage amplifier, signal generator, expander, compressor, 5 stage parameter equalization
  • Output per channel:31 Section diagram equalizer, delay device, frequency divider, limiter
  • Full function matrix remix
  • Built-in automatic camera tracking function
  • Support for scenario presets；
  • Automatic memory protection when power off
  • 1U Whole aluminum chassis

Products Overview:

16 In 16 Out DSP Digital Processor AGC AFS 18dBu Sound Audio Processor

16 In 16 Out DSP Digital Processor AGC AFS 18dBu Sound Audio Processor

(1) DC12V: DC12V /2A power input interface;

(2) PWR: power indicator light, which means the power supply of the equipment is normal; otherwise, the power supply is abnormal;

(3) SYS: Status indicator light. The flashing light indicates normal operation of the device; otherwise, the device fails;

(4) ETHERNET: 10M/100M ETHERNET interface;

(5) RESET: RESET to factory setting, long press for 5 seconds.

(6) RS232: Support central control command and camera tracking,RX: receive data,TX: send data,G: ground wire;

(7) RS485: Supporting camera tracking;

(8) GPIO: GPIO control;

(8) OUTPUT: Analog Output;

(9) INPUT: Analog Input

Specification:

DSP Chip Dual Core Ti 450MHz FLOPS Input Processing Pre-amplifier, signal generator, extender, compressor, 5-segment parameter equalization, inversion, automatic gain, automatic mixing
Output Processing Segment 31 shows equalizer, delay device, frequency divider, limiter, and inverting Matrix Mixing Input and output signal matrix mixing, mixing component control
Automatic camera tracking function Support Scene preset 100 groups of custom Settings
Sampling 48KHz phantom power 48V
Frequency response 20 - 20K Hz,±0.2dB THD+N ≦0.004% @4dBu
Digital to analog dynamic range (A Weighted) 120dB Analog to Digital dynamic range (A Weighted) 114dB
Input Impedance (Balanced) 20kΩ Output impedance (Balanced) 100Ω
EIN(A Weighted) ≤-120 dBu Channel isolation 104dB @1k Hz
Common mode rejection 70dB @80 Hz Maximum input level 18dBu
Maximum output level 18dBu Floor Noise -90dBu
Working Power DC12V/2A Size 482*258*45(mm)；

I/O
Model No. MX-0808-C MX-0808D-C MX-1616-C
No. of analog input 8 8 16
No. of analog output 8 8 16
No. of Dante input × 4 ×
No. of Dante output × 4 ×
Ethernet 1 1 1
RS485 1 1 1
GPIO 2 2 2
Input gain amplification -24～18dB,6dB,Total 7 level
Balanced/non-balanced, Support
MICLINE Support
Each independent 48V phantom power supply Support
DSP Processing
AFC √ √ √
AEC × × ×
ANC × × ×
AM √ √ √
AGC √ √ √
PC Software
PC Software Support
Windows32位 Support
Windows64位 Support
client-side Built-in client, support online download

​Software:

  • ​Our designed PC version control software is the best tool for you to monitor and operate the digital audio processor, which can be used to edit and store scenes (such as meeting mode, artistic performance mode, concert mode, etc.) according to the acoustic characteristics of different functions. The system built-in lock screen function, It can effectively avoid the occurrence of wrong operation.16 In 16 Out DSP Digital Processor AGC AFS 18dBu Sound Audio Processor

Check Products one by one, to make sure all products are working excellent quality..
